Clear Span Design Warehouse Steel Structure Weld Metal Buildings Workshop ISO Approved
Steel Structure Warehouse Maximizing Space Utilization With Clear Span Design
Compared with traditional buildings, steel structure buildings are a new type of building structure form where the entire building is constructed using steel. Its structure mainly consists of components made from section steel and steel plates, such as steel beams, steel columns, and steel trusses.
Specification
The components are connected through welding, bolts, and rivets. Due to their light weight and simple construction, steel structure buildings are widely used in large factories, sports venues, super high-rise buildings, and other fields. Types of steel structure buildings include portal frames, frame structures, truss structures, and grid structure.
Characteristics and Applications
- Portal frame structures have simple force application and clear load transfer paths, with fast construction speed. Widely used in industrial and civil building fields.
- Steel frame structures have strong flexibility and can create larger spaces, often used in multi-story and high-rise buildings.
- Steel truss structures use small-section pipes to form larger-section components, commonly applied in buildings requiring large spans or heights.
- Steel grid structures are highly indeterminate spatial structures with low spatial stress, light weight, and great stiffness, suitable for stadiums and exhibition halls.
Material Description
| Main Structure |
Description |
| Column & Beam |
Made of welded H section Steel, Steel Grade Q355B/Q235B |
| Column & Beam Connection |
High Strength Bolt |
| Column & Foundation Connection |
Pre-embedded Anchor Bolt |
| Secondary Structure |
Description |
| Roof Purlin & Wall Purlin |
C-shape or Z-shape Steel |
| Knee Brace |
Angle Steel |
| Brace |
Steel Rod |
| Tie Bar |
Steel Pipe |
Wall and Roof Panel Options
| Types of wall panels and roof panels |
Applicable Regions and Scenarios |
| Color Steel Sheet |
Areas without winter, preferred for processing workshops and warehouses |
| Color Steel Sheet & Fiberglass Roll Insulation |
Areas with winter but with low requirements of temperature, preferred for warehouses and workshops |
| Insulated Sandwich Panel |
Workshops and warehouses with temperature requirements |
| PU Insulated Sandwich Panel |
Workshops, warehouses and public facilities with high requirements of temperature for the working environment |
Product Packaging
Frequently Asked Questions
1. What kind of customer service do you provide?
We offer comprehensive customer service, including basic design, supporting facilities procurement, and the option to dispatch installation guidance.
2. How about the customer reviews of your company?
We are proud to have received consistently high five-star reviews from our customers, which stand as a testament to our commitment to quality and service.
3. What is your quality inspection process like?
Our strict quality inspection process ensures that every product meets the highest standards of excellence. From raw materials to finished goods, each stage is meticulously inspected to guarantee superior quality.
4. Can you send engineers or a whole team to install my project?
We will give detailed installation drawings for free. We can send engineers as an installation director or a team upon request.
5. Do you accept container loading inspection?
You are welcomed to send an inspector, not only for the container loading, but any time during the production time.
6. Do you offer designing service for us?
Yes, we could design full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) and etc. we can design complex industrial buildings.
7. What is the delivery time?
Delivery time depends on order quantities. In general, the delivery time to the nearest seaport in China will be 40 days after receiving the deposit.
8. How can I get a quotation for my projects?
You can contact us by email, phone, Trade manager and so on 24*7 and you will get a reply within 8 hours.
9. What certifications has your company passed?
Our company has passed professional certifications such as IOS9000, CE, and SGS, ensuring that our products and services meet international standards.
