OEM Design Steel Structure Warehouse Waterproof Wide Span Metal Buildings
Steel Structure Warehouse Prefabrication And Modular Design For Rapid Deployment
Specification
Steel-structure buildings represent a modern construction paradigm, fundamentally distinguishing themselves from traditional structures by being entirely fabricated from steel. These structures primarily encompass steel beams, columns, trusses, and various other components meticulously crafted from section steel and steel plates. These components are seamlessly integrated through welding, bolting, or riveting processes.
Their inherent lightweight and straightforward design facilitate their extensive application in large-scale factories, stadiums, super high-rise buildings, and a multitude of other sectors. Among the prevalent types of steel-building structures, we have portal rigid-frame, frame, truss, and grid structures. Each of these types possesses unique characteristics and finds specific applications:
- Portal-frame structure: Boasts a straightforward force-bearing mechanism and transparent force transmission path, facilitating swift construction timelines. Finds widespread use in industrial and civil buildings, including industrial plants, commercial structures, and cultural/entertainment venues.
- Frame structures: Renowned for their flexibility, allowing for expansive interior spaces. Prominently featured in multi-story and high-rise constructions such as commercial office towers, shopping malls, and conference centers.
- Steel-truss structure: Leverages small cross-section tubes to assemble larger components. Frequently employed in buildings requiring large-span roofs, including bridges, towers, and marine oil-production platforms.
- Steel-grid structure: A sophisticated statically indeterminate space structure distinguished by low spatial stress, lightweight design, high rigidity, and exceptional seismic-resistance capabilities. Ideal for gymnasiums, exhibition halls, petrol stations, and hangars.
Material Description
Main Structure |
Including Column & Beam, Made of welded H section Steel, Steel Grade Q355B/Q235B |
Column & Beam Connection |
High Strength Bolt |
Column & Foundation Connection |
Pre-embedded Anchor Bolt |
Secondary Structure |
Roof Purlin & Wall Purlin: C-shape or Z-shape Steel
Knee Brace: Angle Steel
Brace: Steel Rod
Tie Bar: Steel Pipe |
Types of wall panels and roof panels
Material |
Applicable Regions and Scenarios |
Color Steel Sheet |
Areas without winter, preferred for processing workshops and warehouses |
Color Steel Sheet & Fiberglass Roll Insulation |
Areas with winter but with low temperature requirements, preferred for warehouses and workshops |
Insulated Sandwich Panel |
Workshops and warehouses with temperature requirements |
PU Insulated Sandwich Panel |
Workshops, warehouses and public facilities with high temperature requirements for the working environment |
Product Packaging
Frequently Asked Questions
1. What kind of customer service do you provide?
We offer comprehensive customer service, including basic design, supporting facilities procurement, and the option to dispatch installation guidance.
2. How about the customer reviews of your company?
We are proud to have received consistently high five-star reviews from our customers, which stand as a testament to our commitment to quality and service.
3. What is your quality inspection process like?
Our strict quality inspection process ensures that every product meets the highest standards of excellence. From raw materials to finished goods, each stage is meticulously inspected to guarantee superior quality.
4. Can you send engineers or a whole team to install my project?
We will give detailed installation drawings for free. We can send engineers as an installation director or a team upon request.
5. Do you accept container loading inspection?
You are welcomed to send an inspector, not only for the container loading, but any time during the production time.
6. Do you offer designing service for us?
Yes, we could design full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) and etc. we can design complex industrial buildings like office mansions, super markets, auto dealer shops, shipping malls, 5-star hotels.
7. What is the delivery time?
Delivery time depends on order quantities. In general, the delivery time to the nearest seaport in China will be 40 days after receiving the deposit.
8. How can I get a quotation for my projects?
You can contact us by email, phone, Trade manager and so on 24*7 and you will get a reply within 8 hours.
9. What certifications has your company passed?
Our company has passed professional certifications such as IOS9000, CE, and SGS, ensuring that our products and services meet international standards.
