Home /Products/Steel Shed Construction/Pre Manufactured Steel Shed Construction Q355 Q235 Metal Beam Prefabricated Building

Pre Manufactured Steel Shed Construction Q355 Q235 Metal Beam Prefabricated Building

1000sqm
MOQ
35-55$/sqm
Price
Pre Manufactured Steel Shed Construction Q355 Q235 Metal Beam Prefabricated Building
Features Gallery Product Description Chat Now
Features
Specifications
Keyword: Light Frame Steel Construction
Main Frame: Light Steel Q355 Q235
Window: Aluminum Alloy Window
Door: Sliding Door, Rolling Door
Wall & Roof: Sandwich Panel; Color Steel Sheet
Secondary Structure: Purlin; Brace; Knee Brace Etc
Cladding: Steel Color Sheet
Column & Beam Connection: High Strength Bolt
Accessories: Skylight Belt; Ventilator; Downspout;Gutter Etc
Drawing Design: Drawing Design
Color: Customer's Requirement
Roof Cladding: Corrugated Steel Sheet/Sandwich Panel
Certifications: ISO 9001, CE
Sail Finishing: PVDF/PTFE, Pvc Coated
Crane Capacity: 5Tons*2 Pcs
Structure Type: Light Steel Structre
Frame: Weld Steel Structure Frame
Material: Steel
Price Term: FOB CIF CFR EXW
Design Software: Auto CAD,Teckla
Bracing: Round Bar/Angle Steel/Steel Rod
Lifespan: More Than 50 Years
Downpipe: UPVC
Life Time: 50 Years
Highlight:

Pre Manufactured Steel Shed Construction

,

Industrial Steel Structure Workshop

,

Q235 Metal Beam Prefabricated Building
Basic Infomation
Place of Origin: China
Brand Name: Lanjing
Model Number: LJ-Workshop
Payment & Shipping Terms
Packaging Details: Single Item
Delivery Time: 30-45 days
Payment Terms: TT
Supply Ability: 40,000 Tons per year
Product Description
Pre Manufactured Steel Shed Construction Q355 Q235 Metal Beam Prefabricated Building
Custom Design Steel Structure Construction Strong Metal Beam Prefabricated Building
Steel structure buildings are renowned for their exceptional strength-to-weight ratio and design flexibility. These structures utilize steel columns, beams, and trusses as primary load-bearing elements, enabling large-span spaces without internal columns. Their superior seismic and wind resistance makes them ideal for earthquake-prone regions and areas susceptible to extreme weather conditions.
Key Advantages
  • Rapid construction: Prefabricated components streamline on-site assembly, reducing project timelines by 30-50% compared to traditional methods.
  • Sustainability: Steel is 100% recyclable, minimizing construction waste and supporting circular economy principles.
  • Durability: Galvanized or coated steel resists corrosion, ensuring a lifespan exceeding 50 years with minimal maintenance.
  • Adaptability: Modular designs allow easy expansion or reconfiguration to meet evolving functional requirements.
Widely used in industrial plants, commercial complexes, and agricultural facilities, our steel structures comply with rigorous technical standards including Steel Structure Design Code (GB 50017) and Anti-Seismic Design Specifications (GB 50011). Their combination of efficiency, resilience, and eco-friendliness makes them a cornerstone of modern architectural innovation.
Specification
Item Materials
Main steel frame
Column and beam Q235, Q355 steel, paint or galvanization
Wind resistant column Q235, Q355 steel, paint or galvanization
Secondary bracing
Roof purlin Q235B C/Z section galvanized steel
Wall purlin Q235B C/Z section galvanized steel
Tie bar Q235,φ89*3 round steel pipe
Knee brace Angle steel,Q235,L50*4
Roof horizontal bracing φ20,Q235B steel bar, paint or galvanized
Column vertical bracing φ20,Q235B steel bar, paint or galvanized
Casing pipe φ32*2.0,Q235 steel pipe
Pulling bar Φ10 round bar Q235
Roof and wall
Wall and roof panel Corrugated steel sheet/sandwich panel
Protecting system
Gutter Color steel sheet/galvanized steel/stainless steel
Trim and flashing Color steel sheet
Downspout PVC
Self tapping screw
Fastener system
Anchor bolts Q235 steel
High strength bolt The Specifications shall be determined according to the design of steel structure
Normal bolt
Nuts
Window and door
Window Aluminium windows
Door According to requirement to choose, can be EPS door, windproof door, high-speed roll-up door, industrial sliding door etc.
Pre Manufactured Steel Shed Construction Q355 Q235 Metal Beam Prefabricated Building 0 Pre Manufactured Steel Shed Construction Q355 Q235 Metal Beam Prefabricated Building 1 Pre Manufactured Steel Shed Construction Q355 Q235 Metal Beam Prefabricated Building 2
