Customized Length Sustainable Steel Structure Workshop Construction Fast Build
Product Overview
Sustainable steel structure buildings represent a modern architectural solution, offering faster construction times and greater flexibility compared to traditional buildings. These structures are composed of steel beams, columns, trusses, and other components fabricated from sectional steel and steel plates, interconnected through welding, bolts, and rivets.
Structural Specifications
Our steel building structures are available in several configurations, each suited to specific applications:
- Portal Frame Structure: Simple force distribution, clear transmission path, and rapid construction. Ideal for industrial facilities, commercial establishments, and public facilities.
- Steel Building Frame Structures: Flexible design allowing expansive spaces. Perfect for multi-story and high-rise buildings including office towers and shopping malls.
- Steel Truss Structure: Uses small cross-section tubes to assemble larger components. Suitable for buildings requiring large spans like bridges and towers.
- Steel Grid Structure: Complex space structure with low space stress, lightweight, and high rigidity. Excellent for stadiums, exhibition halls, and large-scale facilities.
Material Specifications
| Main Structure |
Description |
| Column & Beam |
Made of welded H section Steel, Steel Grade Q355B/Q235B |
| Column & Beam Connection |
High Strength Bolt |
| Column & Foundation Connection |
Pre-embedded Anchor Bolt |
| Secondary Structure |
Description |
| Roof Purlin & Wall Purlin |
C-shape or Z-shape Steel |
| Knee Brace |
Angle Steel |
| Brace |
Steel Rod |
| Tie Bar |
Steel Pipe |
Wall and Roof Panel Options
| Panel Type |
Applicable Regions and Scenarios |
| Color Steel Sheet |
Areas without winter, preferred for processing workshops and warehouses |
| Color Steel Sheet & Fiberglass Roll Insulation |
Areas with winter but with low temperature requirements, preferred for warehouses and workshops |
| Insulated Sandwich Panel |
Workshops and warehouses with temperature requirements |
| PU Insulated Sandwich Panel |
Workshops, warehouses and public facilities with high temperature requirements |
Packaging
Frequently Asked Questions
1. What kind of customer service do you provide?
We offer comprehensive customer service, including basic design, supporting facilities procurement, and the option to dispatch installation guidance.
2. How about the customer reviews of your company?
We are proud to have received consistently high five-star reviews from our customers, which stand as a testament to our commitment to quality and service.
3. What is your quality inspection process like?
Our strict quality inspection process ensures that every product meets the highest standards of excellence. From raw materials to finished goods, each stage is meticulously inspected to guarantee superior quality.
4. Can you send engineers or a whole team to install my project?
We will give detailed installation drawings for free. We can send engineers as an installation director or a team upon request.
5. Do you accept container loading inspection?
You are welcomed to send an inspector, not only for the container loading, but any time during the production time.
6. Do you offer designing service for us?
Yes, we could design full solution drawings as your requirements. By using AutoCAD, PKPM, MTS, 3D3S, Tarch, Tekla Structures (Xsteel) and etc. we can design complex industrial buildings like office mansions, super markets, auto dealer shops, shipping malls, 5-star hotels.
7. What is the delivery time?
Delivery time depends on order quantities. In general, the delivery time to the nearest seaport in China will be 40 days after receiving the deposit.
8. How can I get a quotation for my projects?
You can contact us by email, phone, Trade manager and so on 24*7 and you will get a reply within 8 hours.
9. What certifications has your company passed?
Our company has passed professional certifications such as IOS9000, CE, and SGS, ensuring that our products and services meet international standards.
